FIT Invado Thermal Positive CTP Plate

Product Description

FIT Invado Thermal CTP Plate is especially designed for cost-conscious printers, who need medium to long run lengths with high-performance press quality. It uses advanced thermal plate technology to deliver 1-99% at 250 lpi resolutions, which will satisfy general commercial print quality requirements. Manufactured with strict quality control production procedures, FIT Invado is able to provide printers excellent and reliable pre-press and print results.

Product parameters



Type:  Positive thermal CTP Plate
Suitable for:  Medium to long run length commercial printing
Substrate:  High quality grained and anodized aluminum
Maximum width:   1480mm
Spectral sensitivity:   830 nm
Exposure energy:  120-150mj/cm2
Resolution:  1-99%@250 lpi
Run length*:  100,000 unbaked, 1million impressions when post-baked
*Run length depends on processing and printing quality control and conditions.
UV ink compatibility:   Applicable with UV inks when post-baked
 Shelf life:   18 months when stored away from excessive cold, heat and humidity
 Storage conditions:   Store plates flat in their packaging, away from excessive cold,
 heat or high humidity at 5℃~30℃, with RH between 40~80%.
 Post-baking recommendation :   230 ~ 250 ℃ , 5 ~ 8 minutes
